Philips Signage Solutions Video Wall Display

Marketing Information

Make an impact

Designed for 24/7 operation, the Philips X-Line Videowall display captivates customer attention with its immersive moving content. CMND makes managing your promotions and retail content easy, whilst FailOver adds greater peace of mind.

Operate, monitor and maintain with CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures content is always playing

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically... between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

OPS slot allows for PC embedding without cabling

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

Add Android processing power with an optional CRD50 module

Embed an Android System-on-Chip (SoC) in your Philips Professional Display. The optional CRD50 module is an OPS device that enables Android processing power without the need for cables. Simply slide into the OPS slot, which contains all the connections needed to run the module (including power supply).

Tiling mode. Create tiled 4K videowalls of any size

Connect two or more Philips professional displays to create a tiled videowall-without the need for external devices. A single player takes care of content, whether you have four screens or 40. 4K content is fully supported, and if you're showing that content on four screens you get the best possible dot-by-dot resolution.

Ultra-narrow bezels. For distraction-free images

Boost image quality with Pure Colour Pro. Delivering higher luminance through custom colour temperature settings and advanced gamma calibration, content looks crisper and more radiant for stunning realism with a visual pop.

Specifications
Manufacturer: Philips Electronics
Manufacturer Part Number: 55BDL2105X/00
Manufacturer Website Address: http://www.philips.co.uk
Brand Name: Philips
Product Line: X-line
Product Model: 55BDL2105X/00
Product Name: Signage Solutions Video Wall Display
Product Type: Digital Signage Display
Technical Information
Video Wall Compatible: Yes
Display & Graphics
Number of Screens: 1
Screen Size: 55"
Display Screen Type: LCD
Display Resolution: 1920 x 1080
Pixel Pitch: 0.63 mm
Backlight Technology: Direct LED
Video
Scan Format: 1080p
Dynamic Contrast Ratio: 500,000:1
Brightness: 500 cd/m²
Network & Communication
Ethernet: Yes
Interfaces/Ports
USB: Yes
DVI: Yes
HDMI: Yes
DisplayPort: Yes
Serial: Yes
Number of USB 2.0 Ports: 1
Number of HDMI Inputs: 2
Number of DisplayPorts: 1
Number of DVI Ports: 1
Physical Characteristics
VESA Mount Standard: 400 x 400
Mount Type: Wall Mountable
Height: 68.4 cm
Width: 121.4 cm
Depth: 9.8 cm
Weight (Approximate): 28.80 kg
Miscellaneous
Package Contents:

• Signage Solutions Video Wall Display
• 3 x Gap pads
• 1 x IR sensor cable (1.8m)
• 1 x Quick start guide
• remote control
• AAA batteries
• RJ45/RS232 converter
• 3 x Cable Clips
• power cord
• 1 x DP Cable
• 1 x RJ45 Cable
• 2 x Frame Alignment Pin
• 1 x Kit-1
• 2 x Kit-2

Environmental Compliance: Restriction of Hazardous Substances (RoHS)
