HPE ProLiant MicroServer Gen10 Plus V2 Server

Marketing Information

HPE ProLiant MicroServer Gen10 Plus v2

HPE ProLiant MicroServer Gen10 Plus v2 delivers an affordable compact yet powerful entry level server that you can customize for on-premises, hybrid cloud, or even workloads demanding datacenter performance. It has the same design as the previous version and can be placed flat or vertically depending on customer environment. The latest Intel Xeon® E and Pentium® supported processors deliver compute performance as well as security and remote management into the server with HPE iLO silicon root of trust. Along with other enhancements such as 4x 1GbE onboard NICs and USB 3.2 Gen2 Type-A, whether you want a generalpurpose server, NAS or even a virtualization server, you will be s...urprised at how much you can get out of this small and affordable server.

Specifications
Manufacturer: Hewlett Packard Enterprise
Manufacturer Part Number: P54649-421
Manufacturer Website Address: http://www.hpe.com
Brand Name: HPE
Product Line: ProLiant
Product Series: MicroServer Gen10 Plus v2
Product Name: ProLiant MicroServer Gen10 Plus V2 Server
Product Type: Server
Processor
Number of Processors Supported: 1
Number of Processors Installed: 1
Processor Type: Xeon
Processor Model: E-2314
Processor Core: Quad-core (4 Core)
Processor Speed: 2.80 GHz
Cache: 8 MB
Chipset
Chipset Manufacturer: Intel
Chipset Model: C252
Memory
Standard Memory: 16 GB
Maximum Memory Supported: 64 GB
Memory Technology: DDR4 SDRAM
Error Checking: ECC
Total Number of Memory Slots: 2.0
Number of Occupied Memory Slots: 1
Signal Processing: Unregistered (Unbuffered)
Storage
Total Hard Drive Capacity: No
Optical Drive Type: No
Controllers
Controller Type: Serial ATA
Controller Model: VROC
I/O Expansions
Number of Total Expansion Bays: 4
Number of 3.5" Bays: 4
Number of LFF Bays: 4
Hot Swappable Bays: No
Total Number of Expansion Slots: 1.0
PCI Express Details: 1 standard (Low Profile) PCIe 4.0
Network & Communication
Ethernet Technology: Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports: 7
Number of USB 2.0 Ports: 1
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 4
VGA: Yes
Number of VGA Ports: 1
DisplayPort: Yes
Number of DisplayPorts: 1
Operating System
Operating System Supported:

• Windows Server 2019 Essentials
• Windows Server 2019 Standard
• Windows Server 2019 Datacenter
• Hyper-V
• Windows Server 2022 Essentials
• Windows Server 2022 Standard
• Windows Server 2022 Datacenter
• Red Hat Enterprise Linux 8.4

Operating System: No
Power Description
Input Voltage:

• 120 V AC
• 230 V AC

Number of Power Supplies Supported: 1
Number of Power Supplies Installed: 1
Plug/Connector Type: C5
Maximum Power Supply Wattage: 180 W
Redundant Power Supply: No
Physical Characteristics
Form Factor: Ultra Micro Tower
Height: 118.9 mm
Width: 245.1 mm
Depth: 245.1 mm
Weight (Approximate): 7.20 kg
Miscellaneous
Security Features:

• UEFI Secure Boot and Secure Start support
• Immutable Silicon Root of Trust
• FIPS 140-2 validation
• Common Criteria certification
• Configurable for PCI DSS compliance
• Ability to rollback firmware
• Secure erase of NAND/User data
• TPM (Trusted Platform Module) 2.0 option
• Front bezel lock feature, standard
• Padlock slot, standard
• Kensington Lock slot, standard
• Power cord clip, standard

Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Additional Warranty Information:

Server Warranty includes 1- Year Parts, 1-Year Labor, 1- Year Onsite support with next business day response
