AXIS AXIS P4705-PLVE Panoramic Camera

Marketing Information

This dual-sensor, multidirectional camera delivers excellent image quality even in challenging light conditions. Built on ARTPEC-8, it offers support for advanced analytics based on deep learning on the edge.

See it all - 24/7

AXIS P4705-PLVE includes 360° IR illumination with individually controllable LEDs so you'll enjoy clear images even in low light or complete darkness as well as undistorted colors during the day. Featuring AXIS Lightfinder you get color images recorded in near darkness. And Forensic WDR ensures clarity when there's both dark and light areas in the scene. It offers two 2 MP channels and a frame rate of 30 fps letting you capture both wide angle and zoomed-in, detailed views. And,... thanks to 2.5x zoom it delivers wide views and you can zoom in for all the details. Furthermore, audio input allows you to listen in to transactions or incidents.

Brilliant design

This compact, multidirectional camera is perfect when you need to see in two directions simultaneously. It offers flexible positioning of both varifocal camera heads and each head can be controlled individually so you can monitor scenes in two directions in wide or zoomed-in views. The camera's sensors can also be twisted, allowing two camera heads to be positioned closer together. This is the perfect setup for straight hallways or at the corners of an intersection where it can look in both directions simultaneously.

Deep learning on the edge

Built on ARTPEC-8, this high-performance camera includes a deep learning processing unit (DLPU). This enables improved processing and storage capabilities allowing you to collect and analyze even more data than before on the edge. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, AXIS P4705-PLVE can detect and classify humans, vehicles, and types of vehicles all tailored to your specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge.

Cost-efficient installation

With two camera heads in one camera, AXIS P4705-PLVE offers cost-effective installation. That's because there's only one camera to install, one cable to draw, one IP address, one video management software (VMS) license, and just one license for any analytics you choose to install. Including an optional IP66/IP67 rated weather shield, this high performance camera is ideal for outdoor wall mounting. It offers edge storage for added storage capability and reliability. And, thanks to remote zoom and focus capabilities it eliminates the need for hands-on fine tuning and ensures fast and accurate installation. Furthermore, Zipstream with H.264/ H.265 significantly lowers bandwidth and storage requirements.

Specifications
Manufacturer: Axis Communications
Manufacturer Part Number: 02415-001
Manufacturer Website Address: http://www.axis.com/uk
Brand Name: AXIS
Product Line: Panoramic
Product Series: P47
Product Model: P4705-PLVE
Product Name: AXIS P4705-PLVE Panoramic Camera
Product Type: Network Camera
Technical Information
Recording Formats: Full HD
HD Recording: Yes
Night Vision: Yes
Night Vision Distance: 15 m
Night Vision Type: Infrared
Display & Graphics
Image Sensor Type: RGB CMOS
Colour Supported: Colour
Field of View: Horizontal field of view: 107°-39° Vertical field of view: 55°-22° Diagonal field of view: 131°-45°
Effective Camera Resolution: 2 Megapixel
Number of Sensors: 2
Video
Video Formats:

• Zipstream
• H.264
• H.265
• H.264B
• H.264H
• H.264M
• Motion JPEG
• H.264B (MPEG-4 Part 10/AVC)
• H.264M (MPEG-4 Part 10/AVC)
• H.264H (MPEG-4 Part 10/AVC)
• H.265 (MPEG-H Part 2/HEVC)

Maximum Video Resolution: 1920 x 1080
Maximum Frame Rate: 60 fps
Lens
Lens Type: Varifocal
Minimum Focal Length: 3.26 mm
Maximum Focal Length: 8.12 mm
Lens Included: Yes
Minimum Aperture: f/3.2
Maximum Aperture: f/1.9
Optical Zoom: 2.5x
Exposure
Shortest Shutter Speed: 1/20000 Second
Longest Shutter Speed: 1.5 Second
Network & Communication
Connectivity Technology: Wired
Remote Management: Yes
Storage
Storage Type: Memory Card
Interfaces/Ports
Network (RJ-45): Yes
Power Description
Power Source Type: PoE
Physical Characteristics
Mount Type:

• Junction Box Mount
• Tripod Mount
• Gang Box Mount
• Conduit Mount
• Wall Mount

Color Family: Dual Colour
Product Color:

• White
• Black

Height: 88 mm
Width: 133 mm
Length: 208 mm
Weight (Approximate): 975 g
Environmental Conditions
Minimum Operating Temperature: -30°C
Maximum Operating Temperature: 50°C
Maximum Operating Humidity: 100%
Miscellaneous
Features:

• Wide Dynamic Range
• Day/Night
• Human Detection
• Vehicle Detection
• Video Management System
• SD Card Local Storage
• Motion Detection
• Privacy Masking
• Password Protection
• HTTPS Encryption

Indoor/Outdoor: Outdoor
Impact Protection Rating: IK10
Ingress Protection Rating:

• IP66
• IP67
