AOpen QH15s LCD Projector

Specifications
Manufacturer: Acer, Inc
Manufacturer Part Number: MR.JXV11.001
Manufacturer Website Address: http://www.acer.co.uk
Brand Name: AOpen
Product Model: QH15s
Product Name: QH15s LCD Projector
Product Type: LCD Projector
Technical Information
Projection Method:

• Rear
• Front
• Rear Ceiling
• Front Ceiling

Platform Supported:

• Windows
• PC

AI-powered: Yes
Features: AirPlay
Video Compatibility:

• SDTV
• HDTV
• EDTV

Computer Compatibility:...

• Google Chrome PC
• Windows PC

Horizontal Scan Range: 30 kHz - 100 kHz
Vertical Scan Range: 50 Hz - 60 Hz
Offset: 100%
Bluetooth: Yes
Noise Level (Standard Mode): 35 dB
Built-in OS: Android V9.0
Processor & Chipset
Processor Type: Cortex A53
Processor Model: H713
Processor Core: Quad-core (4 Core)
Memory
Standard Memory: 1 GB
Memory Technology: DDR SDRAM
Storage
Flash Memory Capacity: 8 GB
Projection Lens
Lens Type: Manual Focus
Minimum Diagonal Image Size: 889 mm
Maximum Diagonal Image Size: 2.54 m (100")
Optical Zoom: 1x
Minimum Projection Distance: 830 mm
Maximum Projection Distance: 2.78 m
Lamp
Number of Lamps: 1
Lamp Type: Mini LED
Normal Mode Lamp Life: 30000 Hour
High Mode Brightness: 6500 lm
Standard Mode Brightness: 180 lm
Standard Mode Brightness Disclaimer: Compliant with ISO 21119 standard
Colour Supported: 16.7 Million Colours
Native Resolution: 1280 x 720
Graphic Mode: 2K
Maximum Resolution: 1920 x 1080
Native Aspect Ratio: 16:9
Compatible Aspect Ratio: 4:3
Throw Ratio: 1.25 (762 mm@833 mm)
Zoom Ratio: 1:1
Contrast Ratio: 1,000:1
Vertical Keystone Correction: -30°/+30°
Horizontal Keystone Correction: -30°/+30°
Minimum Vertical Sync: 50 Hz
Maximum Vertical Sync: 60 Hz
Minimum Horizontal Sync: 30 kHz
Maximum Horizontal Sync: 100 kHz
Keystone Correction Vertical: 4-corner Correction Vertical +/- 30° (Vertical, Manual & Auto)
Keystone Correction Horizontal: 4-corner Correction Horizontal +/- 30° (Horizontal, Manual)
Video
Video Signal Format:

• NTSC
• PAL
• SECAM

Video Signal Standard: HDTV
Input Scan Format: 720p
Output Scan Format: 480p
Audio
Number of Speakers: 2
Speaker Output Power: 3 W
Speaker Output Mode: Stereo
Speaker Included: Yes
Multimedia Features
Multimedia Playback:

• Photo Slide Show
• Video Playback
• Audio Playback

Supported Multimedia Formats
Audio Formats:

• MP3
• WMA
• AAC
• M5a

Network & Communication
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11ac
Wireless LAN Standard Detail: 802.11a/b/g/n/ac 2.4GHz/5GHz
Wireless Capability: Miracast Wi-Fi
Bluetooth Standard: Bluetooth 5.4
Interfaces/Ports
HDMI: Yes
Number of HDMI Ports: 1
HDMI Detail: HDMI (HDCP) x 1
Total Number of HDMI Ports: 1
Number of USB Ports: 3
USB: Yes
USB Connector Type: 3 x Type-A
USB Detail: DC Out (5V/1A, USB Type A) x 1;USB (Type A) x 1;USB (Type A) x 1
Number Of Audio Outputs: 1
Audio Line Out: Yes
Bluetooth Audio: x1, V 4.2, BT In/Out
USB Type-A Out: x1, DC Out (5V/1A)
Built-in Devices
Built-in Devices: Speaker
Power Description
Input Voltage:

• 120 V AC
• 230 V AC

Input Voltage Range: 120 V AC - 230 V AC
Operating Power Consumption: 60 W
Standby Power Consumption: 500 mW
Power Supply: 100 V AC ~ 240 V AC
Power Supply Input Voltage Range: AC input 100~240V
Physical Characteristics
Form Factor: Ceiling Mountable
Height: 204 mm
Width: 103 mm
Depth: 103 mm
Weight (Approximate): 620 g
Operating Temperature: 0°C to 35°C
Operating Humidity: 80%
Fan Noise: 35 dB Approximate Standard Mode
Installation: Ceiling Mount
Miscellaneous
Package Contents:

QH15s LCD Projector

AC Power Cord

Quick Start Guide

Remote Control

Country of Origin: China
Standard Accessories:

AC Power Cord

Quick Start Guide

Remote Control

Warranty
Additional Warranty Information: EMEA Warranty
