Allied Telesis IE048 240W Power Supply
Efficiency | 94% |
---|---|
Output Power | 240 W |
Product Type | Power Supply |
Input Voltage | 120 V AC/230 V AC |
Output Voltage | 52 V DC/48 V DC |
Features | LED Indicator |
Form Factor | DIN Rail Mountable |
Brand Name | Allied Telesis |
Product Family | IE048 |
Environmental Compliance | Restriction of Hazardous Substances (RoHS)/China Restriction of Hazardous Substances (China RoHS)/Waste Electrical and Electronic Equipment Directive (WEEE) |
Description
The IE048 Series power supplies deliver reliable 48VDC output voltage. They are fully tested and validated to operate with Allied Telesis Industrial products.
Housed in a compact metal case with DIN rail clip, the IE048 features mechanical robustness, electromagnetic compatibility and enhanced thermal characteristics, making it ideal for exposed areas and harsh environments.
Highly efficient and stable output power provides the capability to support 150% of peak load. The nominal output voltage of 48VDC can be adjusted to match application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy... costs by eliminating reactive power and harmonics from power lines.
As well as providing efficiency, the PFC complies with international regulations. It establishes limits on the harmonic currents that can appear on an AC main line.
Specifications
Manufacturer: Allied Telesis, Inc
Manufacturer Part Number: ATIE04824020
Manufacturer Website Address: http://www.alliedtelesis.co.uk
Brand Name: Allied Telesis
Product Series: IE048
Product Name: IE048 240W Power Supply
Product Type: Power Supply
Technical Information
Efficiency: 94%
Power Factor Correction (PFC): Active
Protection Type:
- Over Current
- Over Temperature
- Over Voltage
Features: LED indicator
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Output Voltage:
- 52 V DC
- 48 V DC
Output Voltage Detail: 52 V DC @ 4.6 A
Output Current: 4.60 A
Output Power: 240 W
Input Frequency: 60Hz
Environmental Conditions
Minimum Operating Temperature: -25°C
Maximum Operating Temperature: 70°C
Physical Characteristics
Form Factor: DIN Rail Mountable
Height: 124 mm
Width: 50 mm
Depth: 117 mm
Weight (Approximate): 900 g
Miscellaneous
Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- China Restriction of Hazardous Substances (China RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty: 5 Year
